In adition, remote replay and remote extraction via satellite connection available. “Live Player V5” allows monitoring and playback of collected data on a PC.Optional sensor adapter gathers all the serial/analog/digital sensor data and collectively feeds it to DCU Multiple sensor adapters can be interfaced depending upon the number of sensors to be interfaced.

* Necessary when FURUNO Radar FAR-15x8/FAR- 2xx7, ECDIS FEA-2107/2807 or the products of third-party manufacturers are connected to VR-7000/7000S.

Video LAN converter can convert the Radar signal (DVI or RGB) into Ethernet.

* Radar and ECDIS that utilizes LAN interface based on IEC 61162-450 can be connected through Ethernet.

* Radar and ECDIS images can be recorded at 15-second intervals.

* Up to 5 display images from FURUNO Radar FAR-3000/FCR-2xx9 series or FURUNO ECDIS FMD-3200/3300 can be stored simultaneously through Ethernet without optional SSD.

No.1, 2 Radar and main ECDIS display images can be stored.

Data storing for 30 days/720 hours in SSD in the Data Collecting Unit.

Data storing for 48 hours both in fixed and float-free recording medium.

Complies with the IMO performance standards for VDR and S-VDR.
